Architectural Media Facade Free Form Display
| LED Screen Technical Specifications (Indoor vs Outdoor) | |||||
| INDOOR SPECIFICATIONS | OUTDOOR SPECIFICATIONS | ||||
| Pixel pitch (mm) | P2.604 (indoor) | P2.976 (indoor) | P3.91 (indoor) | P2.976 (outdoor) | P3.91 (outdoor) |
| Lamp model | SMD1515 | SMD2020 | SMD2020 | SMD1415 | SMD2020 |
| Module pixel resolution(dots) | 192*192 | 168*168 | 128*128 | 192*192 | 128*128 |
| Module size(mm) | 250*250 | 250*250 | |||
| Pixel density (dots/m²) | 147474 | 112896 | 65410 | 147474 | 65410 |
| Brightness(nits) | ≥700 | ≥700 | ≥700 | ≥4500 | ≥4500 |
| white color temperature(°) | 6000~10000 | 6000~10000 | 6000~10000 | 6000~10000 | 6000~10000 |
| Viewing angle(°) | H:160 V:140 | H:160 V:140 | H:160 V:140 | H:160 V:140 | H:160 V:140 |
| Panel dimention | 500*500 | 500*500 | 500*500 | 500*500 | 500*500 |
| Cabinet material | Die-casting aluminum | Die-casting aluminum | Die-casting aluminum | Die-casting aluminum | Die-casting aluminum |
| Panel weight | 7.5KG | 7.5KG | 7.5KG | 7.5KG | 7.5KG |
| Grey scale | 14Bit | 14Bit | 14Bit | 14Bit | 14Bit |
| Frame frequency | 60Hz/50Hz | 60Hz/50Hz | 60Hz/50Hz | 60Hz/50Hz | 60Hz/50Hz |
| Refresh rate(Hz) | 3840 | 3840 | 3840 | 3840 | 3840 |
| Driving method | 1/32s | 1/28s | 1/16s | 1/21s | 1/16s |
| Working Voidtage(V) | AC100-240V | AC100-240V | AC100-240V | AC100-240V | AC100-240V |
| Input Power(Hz) | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 |
| Max Power consumption/panel(w) | 480 | 480 | 480 | 480 | 480 |
| Power consumption/panel(w) | 160 | 160 | 160 | 160 | 160 |
| Lifespan(H) | 100000 | 100000 | 100000 | 100000 | 100000 |
| IP Level | IP31 | IP31 | IP31 | IP65 | IP65 |
Elevate your architectural vision with the ICR-O Series, a revolutionary Transparent LED Integrated Glass solution that merges high-definition digital media with structural glazing. Engineered for seamless integration, this “Ice Crystal” technology embeds micro-LEDs and driver chips directly into tempered glass using ITO transparent conductive materials, offering unmatched clarity, vivid color reproduction, and structural durability—ideal for landmarks, luxury retail, and high-end corporate facades
Record-Breaking Transparency – Achieve up to 99% light transmission (at P40 pitch), ensuring natural lighting and unobstructed views while maintaining a crystal-clear aesthetic when the display is inactive.
Invisible Circuitry Technology – Built with ITO (Indium Tin Oxide) transparent conductive layers, eliminating visible wires and bulky hardware for a sleek, “hidden” digital canvas.
Integrated “Sandwich” Engineering – Features a multi-layer tempered glass structure (6mm+3mm+6mm) that shields LEDs from humidity, dust, and external impacts within a vacuum-sealed, high-protection unit.
Large-Scale Seamless Display – Supports massive single-panel customizations (up to 2m wide x 6m high) to minimize structural seams and provide a continuous, high-impact storytelling surface.
Advanced Thermal & Energy Efficiency – Optimized for high-performance cooling with average power consumption as low as 120W/m², reducing operational costs while extending the system’s lifespan to 100,000 hours.
Dual-Sided Visual Impact – Engineered with double-sided display capabilities, allowing your media content to be visible both from the street and within the interior space.
Pro-Grade Control Compatibility – Full integration with industry-standard DMX512, NovaStar, Colorlight, and SPI protocols for precise, real-time synchronization of complex visual effects.
Architectural Resilience – IP65-rated and built with UV-resistant super-white tempered glass, ensuring reliable performance in harsh outdoor environments and temperature extremes from -10°C to +40°C.
