Discover the Sovix SA Series—Featuring Larger Modules, IP66 Waterproof Protection, and Full-Loop Signal Redundancy
| Specification Parameter | MA-3978 | MA-0510 | MA-1010 | |
| Physical properties | ||||
| Pixel pitch (mm) | 3.9 / 7.81 | 5.2 / 10.4 | 10.4 / 10.4 | |
| Pixel density (dot/m²) | 32,768 | 18,432 | 9,216 | |
| LED | SMD1921 (lens) | SMD1921 (lens) | SMD2727 (lens) | |
| Box dimensions (mm) | 1000×500; 500×500 | 1000×500; 500×500 | 1000×500; 500×500 | |
| Box direction | Horizontal/vertical | Horizontal/vertical | Horizontal/vertical | |
| Permeability | 50% | 58% | 58% | |
| Cabinet resolution (dots) | 256×64; 128×64 | 192×48; 96×48 | 96×48; 48×48 | |
| Weight (kg/m²) | 15 | 15 | 15 | |
| Optical properties | ||||
| Brightness (nit) | *Different LED configurations | 4500/8000/8000 | 4500/8000/8000 | 4500/10000 |
| Viewing angle (H/V) | 160° / 160° | 160° / 160° | 160° / 160° | |
| Brightness adjustment | Level 256 (Manual/Automatic) | Level 256 (Manual/Automatic) | Level 256 (Manual/Automatic) | |
| Color temperature (K) | 4,500 – 9,000 (adjustable) | 4,500 – 9,000 (adjustable) | 4,500 – 9,000 (adjustable) | |
| Electronic properties | ||||
| Frame rate (Hz) | 60 | 60 | 60 | |
| Refresh rate (Hz) | 3840 | 3840 | 3840 | |
| Color processing (bit) | 16 | 16 | 16 | |
| Input voltage (V) | AC 100~240V 50/60Hz | AC 100~240V 50/60Hz | AC 100~240V 50/60Hz | |
| Peak power consumption (W/m²) | *Corresponds to different brightness | 720/720/460 | 720/720/460 | 720/320 |
| Average power consumption (W/m²) | 240/240/150 | 240/240/150 | 240/110 | |
| Operating Characteristics | ||||
| Working environment | – 20°C – +50°C / 10%RH-90%RH | – 20°C – +50°C / 10%RH-90%RH | – 20°C – +50°C / 10%RH-90%RH | |
| Storage environment | – 40°C – +60°C / 10%RH-90%RH | – 40°C – +60°C / 10%RH-90%RH | – 40°C – +60°C / 10%RH-90%RH | |
| Heat dissipation method | Natural ventilation | Natural ventilation | Natural ventilation | |
| Protection level | IP65 | IP65 | IP65 | |
| LED life | 100,000 hours | 100,000 hours | 100,000 hours | |
| MTBF | >5,000 hours | >5,000 hours | >5,000 hours | |
| Installation method | Front/Rear Installation | Front/Rear Installation | Front/Rear Installation | |
| Maintenance method | Front/Rear Installation | Front/Rear Installation | Front/Rear Installation | |
Elevate your architectural vision with the ICR-O Series, a revolutionary Transparent LED Integrated Glass solution that merges high-definition digital media with structural glazing. Engineered for seamless integration, this “Ice Crystal” technology embeds micro-LEDs and driver chips directly into tempered glass using ITO transparent conductive materials, offering unmatched clarity, vivid color reproduction, and structural durability—ideal for landmarks, luxury retail, and high-end corporate facades
Record-Breaking Transparency – Achieve up to 99% light transmission (at P40 pitch), ensuring natural lighting and unobstructed views while maintaining a crystal-clear aesthetic when the display is inactive.
Invisible Circuitry Technology – Built with ITO (Indium Tin Oxide) transparent conductive layers, eliminating visible wires and bulky hardware for a sleek, “hidden” digital canvas.
Integrated “Sandwich” Engineering – Features a multi-layer tempered glass structure (6mm+3mm+6mm) that shields LEDs from humidity, dust, and external impacts within a vacuum-sealed, high-protection unit.
Large-Scale Seamless Display – Supports massive single-panel customizations (up to 2m wide x 6m high) to minimize structural seams and provide a continuous, high-impact storytelling surface.
Advanced Thermal & Energy Efficiency – Optimized for high-performance cooling with average power consumption as low as 120W/m², reducing operational costs while extending the system’s lifespan to 100,000 hours.
Dual-Sided Visual Impact – Engineered with double-sided display capabilities, allowing your media content to be visible both from the street and within the interior space.
Pro-Grade Control Compatibility – Full integration with industry-standard DMX512, NovaStar, Colorlight, and SPI protocols for precise, real-time synchronization of complex visual effects.
Architectural Resilience – IP65-rated and built with UV-resistant super-white tempered glass, ensuring reliable performance in harsh outdoor environments and temperature extremes from -10°C to +40°C.
