Discover the Sovix SA Series—Featuring Larger Modules, IP66 Waterproof Protection, and Full-Loop Signal Redundancy
The ICR-O Series is a high-definition, high-transparency display carrier that integrates driver chips and LED light-emitting chips directly onto tempered glass using ITO transparent conductive technology. This “hidden circuit” design allows the glass to maintain its structural integrity and aesthetic clarity while serving as a powerful media canvas.
| Pixel pitches | 4mm | 5mm | 5.71mm | 6.67mm | 8mm | 10mm |
| Pixel density | 62,500 | 40,000 | 30,671 | 22,500 | 15,625 | 10,000 |
| LED type | SMD1921 | SMD1921 | SMD2727 | SMD2727 | SMD2727 | SMD2727 |
| Driving mode | 1/10scan | 1/8scan | 1/7scan | 1/6scan | 1/4scan | 1/2scan |
| Module dimension | 480mm(W) x 320mm(H) | 480mm(W) x 320mm(H) | 480mm(W) x 320mm(H) | 480mm(W) x 320mm(H) | 480mm(W) x 320mm(H) | 480mm(W) x 320mm(H) |
| Module resolution | 120dots * 80dots | 96dots * 64dots | 84dots*56dots | 72dots*48dots | 60dots*40dots | 48dots*32dots |
| Cabinet dimension | 960mm(W) x 960mm(H) | 960mm(W) x 960mm(H) | 960mm(W) x 960mm(H) | 960mm(W) x 960mm(H) | 960mm(W) x 960mm(H) | 960mm(W) x 960mm(H) |
| Cabinet resolution | 240dots * 240dots | 192dots * 192dots | 168dots*168dots | 144dots*144dots | 120dots*120dots | 96dots*96dots |
| Brightness | 6,000nits or 10,000nits | 6,000nits or 10,000nits | 6,000nits or 10,000nits | 6,000nits or 10,000nits | 6,000nits or 10,000nits | 6,000nits or 10,000nits |
| Refresh rate | 3,840Hz | 3,840Hz | 3,840Hz | 3,840Hz | 3,840Hz | 3,840Hz |
| Grayscale | 14bits | 14bits | 14bits | 14bits | 14bits | 14bits |
| Power consumption (max.) | 600W | 600W | 600W | 590W | 580W) | 600W |
| Power consumption (avg.) | 170W | 170W | 170W | 170W | 165W | 170W |
Elevate your architectural vision with the ICR-O Series, a revolutionary Transparent LED Integrated Glass solution that merges high-definition digital media with structural glazing. Engineered for seamless integration, this “Ice Crystal” technology embeds micro-LEDs and driver chips directly into tempered glass using ITO transparent conductive materials, offering unmatched clarity, vivid color reproduction, and structural durability—ideal for landmarks, luxury retail, and high-end corporate facades
Record-Breaking Transparency – Achieve up to 99% light transmission (at P40 pitch), ensuring natural lighting and unobstructed views while maintaining a crystal-clear aesthetic when the display is inactive.
Invisible Circuitry Technology – Built with ITO (Indium Tin Oxide) transparent conductive layers, eliminating visible wires and bulky hardware for a sleek, “hidden” digital canvas.
Integrated “Sandwich” Engineering – Features a multi-layer tempered glass structure (6mm+3mm+6mm) that shields LEDs from humidity, dust, and external impacts within a vacuum-sealed, high-protection unit.
Large-Scale Seamless Display – Supports massive single-panel customizations (up to 2m wide x 6m high) to minimize structural seams and provide a continuous, high-impact storytelling surface.
Advanced Thermal & Energy Efficiency – Optimized for high-performance cooling with average power consumption as low as 120W/m², reducing operational costs while extending the system’s lifespan to 100,000 hours.
Dual-Sided Visual Impact – Engineered with double-sided display capabilities, allowing your media content to be visible both from the street and within the interior space.
Pro-Grade Control Compatibility – Full integration with industry-standard DMX512, NovaStar, Colorlight, and SPI protocols for precise, real-time synchronization of complex visual effects.
Architectural Resilience – IP65-rated and built with UV-resistant super-white tempered glass, ensuring reliable performance in harsh outdoor environments and temperature extremes from -10°C to +40°C.
